Additional components



IGBT - Ignition Module

code: 1832700  75

connector: DEUTSCH AS108-35PN






Lambda Sensor LSU 4.9

code: 1867700 48

connector: DEUTSCH AS607-35PN

Length: 54cm



Planar ZrO2 dual cell limiting current sensor with integrated heater.

Mechanical data:

Weight w/o wire: 120 g

Length: 84 mm

Thread: M18x1.5

Wrench size: 22 mm

Tightening torque: 40...60 Nm

Electrical data:

Power supply H+ nominal: 7.5 V

System supply voltage: 10.8 V...16.5 V

Heater power steady state: 7.5 W

Heater control frequency: ≥ 100 Hz

Nominal resistance of Nernst cell: 300 Ω

Max current load for Nernst cell: 250 μA



Stepper motor (2 types):

flange A type ( X=90°), terminal diameter 8

flange B type ( X=75°), terminal diameter 10








ECU Safety Fixing Kit

including: 3 silent-block, 3 screws, 3 fixing pips






Data Download Cable

Length: 2m

code: 1868000 48


Linear Potentiometer

Length: 75mm and 150mm

code: 1867800 48 - 1867900 48



Miniaturized Linear Potentiometers, based on “conductive plastic” technology, maximum speed of installation and release by “Pop joints” mounting system.

Due to their small size allows installation in smaller spaces.



Ideal for applications such as car suspension, motorcycle forks and shock absorbers, pedals position, etc.


Quickshifter


Quickshifter with load cell technology (Strain Gauge), digital output to be used as shifting

trigger with sensor dimension: Φ=15mm, L=55mm.





Main features:

- Digital output to be used as shifting trigger

- analogue output for data recording from ±50Kg to ±100Kg

- Input force: 4÷40Kg

- Easy user interface with 2 buttons and a led display.

- Automatic temperature, vibrations and creep adjustment

- Sensor dimension: Φ=15mm, L=55mm,

- Provided with an adjustable threaded rod. M6 or M8 threads available.

- IP65 guaranteed

- High reliability: 1,500,000 cycles @65Kgs load passed
